功用与详细介绍/Brief Introduction：

这个机器主要包括特定三通管件包装阀，适用来于水剂和膏霜类物品的包装，特意对高107硅橡胶黏度原辅料（如浓酱、干辣椒酱、番茄酱、种衣剂、微乳剂、漂浮剂等）的特效特别显著的，且高精更高。这个机器主要包括PLC可程序编写调节，搭配6厘米摸屏组队界面显示平台，颁布一键进瓶，一键包装，一键出瓶，电气，油路分配器元零部件均主要包括全球品牌标志，确认了好品质的水平和持续平稳的功能。本系统成分简简单单，实操有利，是全球梦想的面向高107硅橡胶黏度原辅料的包装系统。这个机器具备了以避免渗漏与拉丝工艺工艺的包装闷头，确认包装结束之后后无渗漏，无拉丝工艺工艺。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

性能/Characteristic：

◆的控制软件——所采用三菱数控软件PLC的控制软件，灌装线分子量随机的调准。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆实际操作方法页面——69英寸彩屏手触式实际操作方法页面，准确简易、安全的准确Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆作用优化——上下料有防漏滴装备，可通过原材料基本特征具有下潜罐装作用。（此作用就可以选择）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电嚣元器件——均分为全国知名度项目，保证产品的安全卫生靠谱、准确无误高朝；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆自动化机械器件——机气器件均所按照优良304不锈不銹钢作,如遇还要接触的面积原材料可能所按照316L另计算用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆运算探测——进行运算，对工作任务产品的生产数量形象化揭示。Counting test, real-time, intuitive reflect the yield of work.◆包装论文检测——无瓶不灌、瓶数达不到不灌Bottle filling test - no bottle no filling, not enough◆养护情形——该设备达到GMP标准，可解乏拆卸的、擦拭养护。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆变换外形尺寸——更新装罐外形尺寸时，只需要简简单单变动，轻松自由解决。Changing specifications - change the filling specifications, simply adjust, easy fix.◆干净加装——加装了干净框架结构，使机器设备的操控坏境更有干净公共卫生。（此干净加装是可以加装）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

高技术性能参数/technical parameters：

灌装生产线头数The number of filling head	8头（必选4、6、8、10、1多个装灌头）8 head (opt🥃ional 4, 6, 8, 10, 12 filling head)
适于瓶径 Applicable bottles Drive	Ф33-Ф100 mm
计算精密度较measure precision	±1%
罐装出水量Canned capacity	150-1000ml
生产销售业务能力Production Capacity	2400-4000瓶/小2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
