的主要用途与简单/Brief Introduction：

该线由渐近线式螺杆式洗瓶烘干机阶段集成机、补血口服液液分装轧盖机二台单人根据，划分为洁净、潮湿杀菌和分装密封四个事情区，全新可联调出产，也可单人操作。可完毕淋水、超声心动图波洁净、冲水、冲气、烘干机阶段杀菌、放凉、分装、理盖、戴盖、轧盖等步骤。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

基本特征/Characteristic：

用到超声洗掉波洗掉及水雾轮换冲洗器、远红外高的温度高压蒸汽灭菌、空头灌装生产线与封口处等方法。整线三级联动主动调节。基本操作简单易行非常方便，进行了机电工程一起化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

水平参数值/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
可用规格型号 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(当中常规作业36Kw)(including normal working 36 kw)
机器人毛重machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
